Sundance Louvered Pergola

Most pergolas have square gutters, however, Sundance designed a beautiful, heavy duty extruded aluminum gutter with a 'crown molding style.'

This gutter also has the deepest and largest volume along with 2 shelves for LED lighting!

6"x6" extruded aluminum posts in 6063 T6 heavy grade aluminum, which can be used as a downspout for water redirection. Other post options available.

2"x8" extruded aluminum beams in 6063 T6 (aircraft aluminum) for longer spans between posts, reaching up to 16' x 24'.

Innovative spring pins for louver installation and servicing, drastically decreasing installation and service time.

150 ° louver opening to allow the clients to adjust their pergola whenever their needs... more sun or more shade. This also lets you trap heat on cold days and release heat on the hot days.

The ONLY gutter that readily accepts gutter screens to easily block those pesky leaves.

Double skin insulated louvers which reduce the heat transfer to bottom. Since our louvers trap air, they are the only louvers on the market that offer insulation along with their other perks.

4 structural girders inside the tectonic arch louver and 2 vertical stabilizers outside the louver resulting in the longest span and strongest snow load capacity in the industry! Up to 16' x 24' **Note: the maximum single zone size is based on snow loads for your area. Contact us for more information.**

When the ceiling is complete closed, it will appear to have a flat, tongue-&-groove ceiling feel. They are the only louvers in the industry that appear flat when the roof is closed.

Louvers have a bumper or gasket to resist leaks & give a quieter operation. The only louvers out there with any type of gasket preventing leaks even with the heaviest storms.

The louvers are also mounted on low friction ball bearings on each end. This is the only louvered roof with ball bearings. Ball bearings reduce noice, eliminate wear & tear, and provide even more longevity to this top-of-the-line system.
